SPECIFICATIONS AND OPTIONS
12
IC-M410BB/IC-M510BB EUR Version
D General
• Frequency coverage: TX 156.025 ~ 161.425 MHz
RX 156.050 ~ 162.000 MHz
DSC (CH70) 156.525 MHz
AIS (CH A/B)* 161.975 MHz/162.025 MHz
• Mode: 16K0G3E (FM), 16K0G2B (DSC), 16K0G2B (AIS)*
• Operating temperature range: –20°C ~ +60°C
• Current drain (at 13.8 V): TX high (25 W) 5.5 A maximum
RX Maximum audio 1.5 A maximum (HM-195 × 1)
IC-M410BB
4.0 A maximum
(RX Hailer × 2)
IC-M510BB
4.5 A maximum
(RX Hailer × 3)
• Power supply requirement: Negative ground 12.0 V DC (10.8 ~ 15.6 V DC)
• Antenna impedance:
• Dimensions: Transceiver
216 (W) × 79 (H) × 113 (D) mm
Command microphone 67.5 (W) × 144.5 (H) × 37 (D) mm
• Weight (approximate): IC-M410BB 870 g
IC-M510BB 890 g
Command microphone 400 g
D Transmitter
• Output power: 25 W or 1 W
• Modulation system: Variable reactance frequency modulation
• Maximum frequency deviation: ±5 kHz
• Spurious emissions:
• Frequency error
• Adjacent channel power: More than 70 dB
• Audio harmonic distortion:
• Residual modulation: More than 40 dB
• Audio frequency response: +1 dB to –3 dB of 6 dB octave from 300 Hz to 3000 Hz
D Receiver
• Receive system: Double conversion superheterodyne
• Sensitivity: FM –2
DSC (CH70) –7
AIS*
• Squelch sensitivity:
• Intermodulation rejection ratio: FM More than 68 dB
• Spurious response: FM More than 70 dB
• Adjacent channel selectivity: FM More than 70 dB
• Audio output power:
Command microphone 2 W
External Speaker 13 W (with
• Hum and noise: More than 40 dB
• Audio frequency response: +1 dB to –3 dB of –6 dB octave from 300 Hz to 3000 Hz
* For only the IC-M510BB.
