STEEL LOADBAR SET 2000KG
LOADBAR DIMENSION
A B
600 mm
1000 mm
570
970
546
946
HEAVY DUTY LOADBAR SET 3000KG
Length
Width
Height
1000
200
115
Page 26 FX41 User Manual 08May08
A B
TOP BOTTOM
LOA D
AREA
LOAD
AREA
12515 60
126 152
80
800
80
960
160 200
160 200
Ø
16
Ø 14
TOP
BOTTOM
