Record
● This sets analog inputs 1-4 to both USB ports 1 and 2 on their 1-4 inputs
● USB Port 1’s outputs 1-4 to USB port 2’s inputs 5-8
● USB port 2’s outputs 1-4 to USB port 1’s inputs 5-8
DAW input list for Record mode:
USB1
USB2
1
Analog input 1
1
Analog input 1
2
Analog input 2
2
Analog input 2
3
Analog input 3
3
Analog input 3
4
Analog input 4
4
Analog input 4
5
USB port 2: output 1
5
USB port 1: output 1
6
USB port 2: output 2
6
USB port 1: output 2
7
USB port 2: output 3
7
USB port 1: output 3
8
USB port 2: output 4
8
USB port 1: output 4
Play USB 1
● This sets Audio inputs 1-4 to both USB ports 1 and 2 on their 1-4 inputs
● USB Port 1’s outputs 1-2 to USB Port 2’s inputs 5-6
● USB port 2’s outputs 1-2 to USB port 1’s inputs 5-6.
● The mix configuration is the main difference between Play USB1 and Play USB2, which can be
seen in the mixer settings: the audio signal from the analog inputs are not passed to Analog
outputs 1/2, Analog outputs 3/4, or the Headphones mix.
DAW input list for Play USB1 mode:
USB 1
USB 2
1
Analog input 1
1
Analog input 1
2
Analog input 2
2
Analog input 2
3
Analog input 3
3
Analog input 3
4
Analog input 4
4
Analog input 4
5
USB port 2: output 1
5
USB port 1: output 1
6
USB port 2: output 2
6
USB port 1: output 2
7
USB port 2: output 3
7
USB port 1: output 3
8
USB port 2: output 4
8
USB port 1: output 4
AUDIO4c User Guide v2021-0002 Page 14
