PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.2 Connector Summary
Table 2-1 Summary Table
Nbr
Description
Type of Connections
Pin nbrs.
J1
CF Master/Slave Switch
Slide Switch
ON/OFF
J3
USB
External USB Connector
6-pin
J4
USB
External USB Connector
6-pin
J5
USB (Optional)
2.0mm 5-pin wafer
5-pin
J8
PS/2 Keyboard
2.54mm 5-pin box header
5-pin
J9
PS/2Keyboard
External Mini DIN Socket
6-pin
J10
COM2(RS232/422/485)
External D-Sub Male Connector
9-pin
J14
VGA
2.0mm 10-pin box header
10-pin
J18
Micro SD Card Socket
Micro SD socket
J23
Audio Line-Out
1.25mm Phone Jack
J24
Audio Mic-In
2.0mm 4-pin wafer
4-pin
J25
COM3 (TX, RX)
1.25mm 3-pin wafer
3-pin
J26
COM4 (TX, RX
1.25mm 3-pin wafer
3-pin
J30
SOM CPU Board Socket
SOM CPU Board Socket
200-pin
J31
4-Wires Touch connector
1.25mm 4-pin wafer
4-pin
J32
USB (Wi-Fi Optional)
Internal USB Connector
6-pin
RJ45
Ethernet
External RJ45 Connector
8-pin
PWR
Power Connector (5A)
External Mini DIN Socket
3-pin
PWR
Power Connector (8A)
External Power Plug
2-pin
CF1
CF Card Socket
CF Type I/II Socket
