Icop PMX-090T - System Mapping

16
PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.6 System Mapping
Table 2-2 Technical Data Sheet
Technical Data Sheet
Product Name
PMX-090T-8A DM171C
Doc.No.
QMT1000014R00
Product
Description
9” Vortex86MX Panel PC with 1GB
DDR2 / 2USB / Line-out
/ LAN / 1COM / CF / MicroSD
Doc. Category
Confidential
Issued Date
10-08-2012
System Mapping
Memory Mapping
Address
Description
Usage
00000000-0009FFFF
System RAM
*
000A0000-000AFFFF
EGA/VGA Video Memory
*
000B0000-000B7FFF
MDA RAM, Hercules Graphics
Display RAM
*
000B8000-000BFFFF
CGA Display RAM
*
000C0000-000C7FFF
EGA/VGA BIOS ROM
*
000C8000-000CFFFF
Boot ROM Enable
000CC000-000CFFFF
Console Redirection Enable
000D0000-000D7FFF
Expansion ROM Space
000D8000-000DBFFF
SPI FLASH Emulation Floppy A
Enable
000DC000-000DFFFF
Expansion ROM Space
000E0000-000EFFFF
USB Legacy SCSI ROM Space
000F0000-000FFFFF
Motherboard BIOS
*
FEBD9000-FEBD90FF
Standard OpenHCD USB Host
Controller
*
FEBDA000-FEBDA0FF
Standard OpenHCD USB Host
Controller
*
FEBDB400-FEBDB4FF
On board Ethernet Adapter
*
