Icop PMX-090T - Table of Contents

iii
PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
Table of Contents
1 General Information .............................................................................. 3
1.1 Product Description ...................................................... 1
1.2 Product Specification ................................................... 2
1.3 Inspection standard for TFT-LCD Panel ........................ 4
1.4 Product Dimension ....................................................... 7
1.5 Ordering Information ................................................... 8
1.6 Packing List ................................................................... 8
2 System Installation ................................................................................ 9
2.1 CPU Board Outline ........................................................ 9
2.2 Connector Summary................................................... 10
2.3 Connector Pin Assignments ........................................ 11
2.4 External I/O Overview ................................................ 13
2.5 External I/O Pin Assignment ....................................... 14
2.6 System Mapping ......................................................... 16
2.7 Watchdog Timer ......................................................... 20
3 Driver Installation ................................................................................ 21
3.1 PMX-090T Development Note ................................... 22
3.2 BIOS Default setting ................................................... 24
Warranty ......................................................................................................... 25
