12
PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
J14: VGA
Pin #
Signal Name
Pin #
Signal Name
1
R OUT
2
GND
3
G OUT
4
GND
5
B OUT
6
GND
7
HSYNC
8
GND
9
VSYNCD
10
GND
J24: MIC-IN
Pin #
Signal Name
1
MICVREF
2
GND
3
GND
4
MIC-IN
J25: COM3 (TX, RX)
Pin #
Signal Name
1
GND
2
TXD3
3
RXD3
J26: COM4 (TX, RX)
Pin #
Signal Name
1
GND
2
TXD4
3
RXD4
J31: 4-Wires Touch connector
Pin #
Signal Name
1
Y-
2
X-
3
Y+
4
X+
J32: USB (WiFi Optional)
Pin #
Signal Name
Pin #
Signal Name
1
VCC
2
USBD2-
3
USBD2+
4
GND
5
GND
6
GND
PWR: Power Connector (5A)
Pin #
Signal Name
1
+5V
2
GND
3
NC
4
GND
PWR: Power Connector (8A)
Pin #
Signal Name
1
+ 8 ~ 35V
2
GND
