18
PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
0098h - 009Ch
GPIO Direction Control
*
00A0h - 00A1h
PIC 8259-2
*
00C0h - 00DFh
DMA 8237-2
*
00E0h - 00EFh
DOS 4G Page Access
*
0170h - 0177h
IDE1 (IRQ 15)
*
01F0h - 01F7h
IDE0 (IRQ 14)
*
0220h - 0227h
COM8 Forward to LPC BUS
0228h - 022Fh
COM7 Forward to LPC BUS
0238h - 023Fh
COM6 Forward to LPC BUS
0278h - 027Fh
Printer Port (IRQ 7, DMA 0)
02E8h - 02EFh
COM4 (IRQ 11)
02F8h - 02FFh
COM2 (IRQ 3)
0338h - 033Fh
COM5 Forward to LPC BUS
0376h
IDE1 ATAPI Device Control Write
only Register
*
03E8h - 03EFh
COM3 (IRQ 10)
03F0h - 03F7h
Floppy Disk (IRQ 6, DMA 2)
03F6h
IDE0 ATAPI Device Control Write
only Register
*
03F8h - 03FFh
COM1 (IRQ 4)
*
0480h - 048Fh
DMA High Page Register
*
0490h - 0499h
Instruction Counter Register
*
04D0h - 04D1h
8259 Edge,/ Level Control Register
*
0CF8h - 0CFFh
PCI configuration port
*
DE00h - DEFFh
On Board LAN
*
FC00h - FC05h
SPI Flash BIOS Control Register
(internal SPI Flash Base address)
*
FC08h - FC0Dh
External SPI BUS Control Register
( Output Pin Configurable
GPIO3[0-3] )
