2.6. Mounting the Hardware

 Wall/Panel mounting

Step 1: Install the four mounting screws into the 4 keyhole mounting holes.

Step 2: Fasten the screws securely.

 DIN Rail mounting

Step 1: Align the screw holes of the DIN-rail clip with the holes on the back side of the module,

and then fasten the screws securely.
