ICP Electronics JUKI- 745E - Page 11

9
•
Power module JP1 CPU Core Voltage Select
1-2 3-4 5-6 7-8 9-10 Voltage
ON ON ON ON OFF 3.5V
OFF ON ON ON OFF 3.4V
OFF OFF ON ON OFF 3.2V
ON OFF OFF ON OFF 2.9V
OFF OFF OFF ON OFF 2.8V
OFF ON OFF OFF OFF 2.2V
OFF OFF OFF OFF OFF 2.0V
•
JP34 & JP35 : CPU Single / Dual Power type setting
JP34 JP35
SINGLE
1-2 ON
3-4 ON
1-2 OFF
3-4 OFF
DUAL
1-2 OFF
3-4 OFF
1-2 ON
3-4 ON
•
Cyrix 6x86MX PR Rating Table
( Vcore : 2.9V,dual voltage )
PR Rating Bus MHz CPU Core
MHz
Clock
Multiplier
6x86MX-PR133 50 100 2x
6x86MX-PR133 55 110 2x
6x86MX-PR150 60 120 2x
6x86MX-PR150 50 125 2.5x
6x86MX-PR166 66 133 2x
6x86MX-PR166 55 138 2.5x
6x86MX-PR166 50 150 3x
6x86MX-PR166 60 150 2.5x
6x86MX-PR200 55 165 3x
6x86MX-PR200 66 166 2.5x
6x86MX-PR200 60 180 3x
6x86MX-PR233 66 200 3x
6x86MX-PR266 66 233 3.5x
