ICP Electronics JUKI- 745E - DiskOnChip Flash Disk Configuration; LCD Voltage Configuration

10
•
AMD K6 MMX Rating Table, dual voltage
Product Name Core Freq Vcore Bus MHz Multiplier
K6-233 model 6 233MHz 3.2V 66 3.5x
K6-200 model 6 200MHz 2.9V 66 3x
K6-166 model 6 166MHz 2.9V 66 2.5x
K6-300 model 7 300MHz 2.2V 66 4.5x
K6-266 model 7 266MHz 2.2V 66 4x
K6-233 model 7 233MHz 2.2V 66 3.5x
2.3 DiskOnChip™ Flash Disk
The DiskOnChip™ Flash Disk Chip(DOC) is produced by M-Systems.
Since the DOC is 100% software compatible to hard disk and DOS,
customer don’t need to install any extra software utility. Its “plug
and play” function is not only easy to use but also reliable. It will
share 8KB memory of window.
•
JP36 : DiskOnChip Memory Address Setting
Address JP36
CE000 1-2
D6000 3-4
DE000 5-6
RESERVE 7-8
2.4 LCD Voltage Setting
The JUKI-745E supports 3.3V or 5V LCD panel through jumper
setting. This setting will control the CN3’s Pin 29 & 30 as 3.3V or
5V output.
•
JP39 : LCD Voltage Setting
Function JP39
+3.3V 1-2
+5V 2-3
