3.3 Parallel Port
This port is usually connected to a printer. JUKI-745E includes an
on-board parallel port, accessed through a 26-pin flat-cable
connector CN26.
•
CN26 : Parallel Port Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 STROBE# 14 AUTO FORM FEED #
2 DATA 0 15 ERROR #
3 DATA 1 16 INITIALIZE
4 DATA 2 17 PRINTER SELECT LN #
5 DATA 3 18 GROUND
6 DATA 4 19 GROUND
7 DATA 5 20 GROUND
8 DATA 6 21 GROUND
9 DATA 7 22 GROUND
10 ACKNOWLEDGE 23 GROUND
11 BUSY 24 GROUND
12 PAPER EMPTY 25 GROUND
13 PRINTER SELECT 26 NC
