ICP Electronics JUKI- 745E - External Switches and Indicators

17
3.6 External Switches and Indicators
There are many external switches and indicators for monitoring
and controlling your CPU board.
•
CN2: Speaker Connector
PIN NO. DESCRIPTION
1 +5V
2 Speaker Signal
•
CN38 : Reset Connector
PIN NO. DESCRIPTION
1 External Reset
2 GROUND
•
CN32 : IDE LED Connector
PIN NO. DESCRIPTION
1 +5V
2 HDD LED
•
CN24 : FAN Connector
PIN NO. DESCRIPTION
1 N/C
2 +12V
3 GROUND
