3.5 Keyboard / Mouse Connector
The JUKI-745E provides two keyboard/Mouse connectors.
•
CN37 : 5-pin Header Keyboard Connector
PIN NO. DESCRIPTION
1 KEYBOARD CLOCK
2 KEYBOARD DATA
3 N/C
4 GROUND
5 +5V
•
CN35 : 5-pin Header Mouse Connector
PIN NO. DESCRIPTION
1 MOUSE DATA
2 N/C
3 GROUND
4 +5V
5 MOUSE CLOCK
•
CN36 : 6-pin Mini-DIN Keyboard/Mouse Connector
PIN NO. DESCRIPTION
1 KEYBOARD DATA
2 MOUSE DATA
3 GROUND
4 +5V
5 KEYBOARD CLOCK
6 MOUSE CLOCK
