SERVICE MANUAL R−410A Ductless Split System: DLF4(A/H), DLC4(A/H)
421 08 9204 00 5
PRODUCT SPECIFICATIONS (Cont.)
Model − Outdoor Unit DLC4AV12J1A DLC4HV12J1A
Compressor
Manufacturer Sanyo Sanyo
Model C−6RZ110H1A C−6RZ110H1A
Type Twin Rotary Twin Rotary
L.R.A. A 33 33
R.L.A. A 4.59 / 2.81 4.59 / 2.81
Power Input W 775 / 735 775 / 735
Overload Protectorr Int11I−3979 Int11I−3979
Throttling Method
Electronic Expansion Valve
Throttling
Electronic Expansion Valve Throttling
Starting Method Transducer Starting Transducer Starting
Working Temperature Range °F 55 ~ 115 55 ~ 115 5 ~ 75
Heat Exchanger Coil
Coil
Aluminum Fin−Copper
Tube
Aluminum Fin−Copper Tube
Pipe Diameter inch f0.4 f0.4
Rows−Fin Gap inch 2−0.06 2−0.06
Coil Length (I) x Height (H) x Width (L) inch 30.2 x 20 x0.9 30.2 x 20 x0.9
Fan Motor
Speed rpm 900 / 680 900 / 680 900
Output of Fan Motor W 40 40
R.L.A. A 0.17 0.17
Capacitor mF / /
Air Flow Volume of Outdoor Unit Ft
3
/min 1118 1118
Fan
Type Axial Fan Axial Fan
Diameter inch 15.7 15.7
Defrosting Method / Auto Defrost
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating Pressure for
the Discharge Side
Mpa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side
Mpa 1.2 1.2
Sound Pressure Level DB (A) ≤53 ≤53
Sound Power Level DB (A) ≤65 ≤65
Dimensions (WxHxD) inch 33 X 21 X 12.6 33 X 21 X 12.6
Dimensions of Package (WxHxD) inch 34.5 X 22.8 X 14.2 34.5 X 22.8 X 14.2
Net Weight / Gross Weight Lbs. 107 / 118 107 / 118
Refrigerant
Name of Refrigerant R410A R410A
Weight Oz. 45.5 45.5
Connection Pipe
Length (m) Ft. 16 16
Gas Additional
Charge
Oz/ft 1.1613 1.1613
Liquid Pipe Diameter inch f1/4 f1/4
Gas Pipe Diameter inch f3/8 f3/8
Max. Interunit height Difference Ft. 33 33
Max. Interunit Piping Length Ft. 66 66
* The above data is subject to change without notice. Please refer to the nameplate of the unit.
