SERVICE MANUAL R−410A Ductless Split System: DLF4(A/H), DLC4(A/H)
6 421 08 9204 00
PRODUCT SPECIFICATIONS (Cont.)
Model DLC4AV12K1A DLC4HV12K1A
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity (Min − Max) Btu/h 12000 (3100−13000) 12000 (3100−13000)
Heating Capacity (Min. − Max) Btu/h N/A 13000 (2400−14000)
Cooling Power Input (Min. − Max.) W 1000 (365−1080) 1000 (365−1080)
Heating Power Input (Min. − Max.) W N/A 1000 (340−1360)
Cooling Current Input A 4.5 4.5
Heating Current Input A N/A 5.2
Rated Input W 1500 1500
Rated Current A 15 15
Air Flow Volume (S/H/M/L) CFM 335/277/253/218 335/277/253/218
Dehumidifying Volume Pint/h 2.959 2.959
EER Btu/hW 12 12
COP Btu/hW N/A 10.8
SEER 20 20
HSPF N/A 9.2
Application Area m
2
16−24 16−24
Model − Indoor Unit DLF4AH12K1A DLF4HH12K1A
Indoor Unit
Fan Type Cross−flow Cross−flow
Fan Diameter Length (DXL) inch f3.6x25.4 f3.6x25.4
Cooling Speed (S/H/M/L) r/min 1330/1100/950/750 1330/1100/950/750
Heating Speed (S/H/M/L) r/min N/A 1350/1170/1050/950
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor mF 1 1
Evaporator Form W Aluminum Fin−Copper Tube Aluminum Fin−Copper Tube
Evaporator Pipe Diameter inch f0.27 f0.27
Evaporator Row−fin Gap inch 2−0.05 2−0.05
Evaporator Coil Length (LxDxW) inch 22.8x1x10.4 22.8x1x10.4
Swing Motor Model MP24AA MP24AA
Swing Motor Power Output W 2.4 2.4
Fuse Current A 3.15 3.15
Sound Pressure Level (S/H/M/L) dB (A) 42/39/36/33 42/39/36/33
Sound Power Level (S/H/M/L) dB (A) 52/49/46/43 52/49/46/43
Dimension (WxHxD) inch 33.3X10.8X7 33.3X10.8X7
Dimension of Carton Box
(WxHxD)
inch 36X10X14 36X10X14
Dimension of Package (WxHxD) inch 36X10.1X14.6 36X10.1X14.6
Net Weight lb 22 22
Gross Weight lb 28.7 28.7
