SERVICE MANUAL R−410A Ductless Split System: DLF4(A/H), DLC4(A/H)
421 08 9204 00 7
PRODUCT SPECIFICATIONS (Cont.)
Model − Outdoor Unit DLC4AV12K1A DLC4HV12K1A
Compressor
Manufacturer Mitsubishi Mitsubishi
Model KNB092FTAMC KNB092FTAMC
Oil FV50S FV50S
Type Rotary Rotary
L.R.A. A 13.8 13.8
R.L.A. A 3.2 3.2
Power Input W 860 860
Overload Protector INT11L−6578 INT11L−6578
Throttling Method Electronic Expansion Valve Electronic Expansion Valve
Set Temperature Range °F 60.8 ~ 86 60.8 ~ 86
Cooling Operation Ambient Temperature Range °F 0.4 ~ 109.4 0.4 ~ 109.4
Heating Operation Ambient Temperature Range °F N/A −5 ~ 75.0
Condenser
Form Aluminum Fin−copper Tube Aluminum Fin−copper Tube
Pipe Diameter inch f0.37 f0.37
Rows−Fin Gap inch 2−0.05 2−0.05
Coil Length (LxDxW) inch 29.4x1.7x22 29.4x1.7x22
Fan Motor
Speed rpm 680 / 900 680 / 900
Output of Fan Motor W 30 30
R.L.A. A 0.13 0.13
Capacitor mF N/A N/A
Air Flow Volume of Outdoor Unit CFM 941.6 941.6
Fan
Type Axial Flow Axial Flow
Diameter inch 15.748 15.748
Defrosting Method N/A Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating Pressure for the
Discharge Side
Mpa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side
Mpa 2.5 2.5
Sound Pressure Level (H/M/L) DB (A) 52/−/− 52/−/−
Sound Power Level (H/M/L) DB (A) 62/−/− 62/−/−
Dimensions (WxHxD) inch 33.4x23.2x12.6 33.4x23.2x12.6
Dimensions of Carton Box (WxHxD) inch 34.5x14.2x24.8 34.5x14.2x24.8
Dimensions of Package (WxHxD) inch 34.7x14.3x25.4 34.7x14.3x25.4
Net Weight / Gross Weight Lbs. 88.2 / 97.02 88.2 / 97.02
Refrigerant
Name of Refrigerant R410A R410A
Weight Oz. 45.864 45.864
Connection Pipe
Length inch 25 25
Gas Additional Charge Oz/ft 0.53 0.7
Liquid Pipe Outer Diameter inch 1/4 1/4
Gas Pipe Outer Diameter inch 3/8 3/8
Max. Interunit height Difference Ft. 33 33
Max. Interunit Piping Length Ft. 66 66
* The above data is subject to change without notice. Please refer to the nameplate of the unit.
