SERVICE AND TECHNICAL SUPPORT MANUAL Gas Furnace: (F/G)9MVE
Specifications subject to change without notice.
16 440 04 4800 00
Table 5 (cont.) COOLING
4
AND HEATING AIR DELIVERY - CFM (Bottom Return
5
with filter)
Unit Size Cooling Switch Settings External Static Pressure (ESP)
SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
080-20
Clg Default: OFF OFF OFF 1905 1870 1825 1785 1750 1700 1665 1625 1560 1460
Cooling (SW2)
OFF OFF ON 950 770 620 515 440 365 See note 4
OFF ON OFF 1015 935 880 825 765 690 625 580 See note 4
OFF ON ON 1155 1105 1040 990 920 875 815 755 710 645
ON OFF OFF 1335 1290 1245 1190 1145 1085 1040 990 930 890
ON OFF ON 1520 1485 1435 1390 1340 1300 1255 1200 1160 1115
ON ON OFF 1905 1870 1825 1785 1750 1700 1665 1625 1560 1460
ON ON ON 2290 2230 2160 2085 2005 1915 1820 1730 1640 1525
Clg SW2: Maximum Clg Airflow
2
2290 2230 2160 2085 2005 1915 1820 1730 1640 1525
Heating
(SW1)
High Heat Airflow
3
1575 1535 1485 1445 1400 1350 1310 1260 1215 1170
Low Heat Airflow
3
1230 1170 1125 1065 1015 955 900 855 795 755
100-20
Clg Default: OFF OFF OFF 1890 1845 1800 1755 1700 1655 1610 1560 1510 1460
Cooling (SW2)
OFF OFF ON 1015 825 630 485 405 325 See note 4
OFF ON OFF 1080 895 815 740 690 615 555 475 See note 4
OFF ON ON 1155 1080 1020 940 890 825 785 710 660 590
ON OFF OFF 1310 1260 1195 1140 1075 1025 970 925 875 810
ON OFF ON 1520 1475 1425 1365 1315 1255 1210 1155 1110 1055
ON ON OFF 1890 1845 1800 1755 1700 1655 1610 1560 1510 1460
ON ON ON 2290 2230 2160 2085 2005 1915 1820 1730 1640 1525
Clg SW2: Maximum Clg Airflow
2
2290 2230 2160 2085 2005 1915 1820 1730 1640 1525
Heating
(SW1)
High Heat Airflow
3
1905 1865 1825 1775 1730 1685 1640 1590 1545 1490
Low Heat Airflow
3
1480 1435 1375 1330 1265 1215 1160 1115 1060 1005
120-22
Clg Default: OFF OFF OFF 2010 1960 1910 1850 1800 1750 1690 1645 1565 1480
Cooling (SW2)
OFF OFF ON 1015 805 645 550 480 See note 4
OFF ON OFF 1075 975 915 835 765 See note 4
OFF ON ON 1205 1135 1055 1000 935 See note 4
ON OFF OFF 1400 1330 1260 1190 1145 1080 1035 970 905 845
ON OFF ON 1615 1550 1500 1435 1370 1325 1265 1215 1160 1110
ON ON OFF 2010 1960 1910 1850 1800 1750 1690 1645 1565 1480
ON ON ON note 8 2375 2300 2205 2115 2010 1890 1750 1645 1550
Clg SW2: Maximum Clg Airflow
2
note 8 2375 2300 2205 2115 2010 1890 1750 1645 1550
Heating
(SW1)
High Heat Airflow
3
note 8 2375 2300 2205 2115 2010 1890 1750 1645 1550
Low Heat Airflow
3
1735 1675 1625 1560 1500 1455 1395 1345 1285 1225
*See Notes following table.
