ICP OCF105A12C - Page 9

CORRECT BAND
OVERLAP
FIGURE 1.9 FIGURE 1.10
FIGURE 1.7 FIGURE 1.8
SEALANT FLOWING OUT FROM UNDER BAND CLAMP AT
TERMINAL
SEALANT OUTFLOW
FIGURE 1.11
1
0
APPLY THE
SEALANT TO THE
TUBE END
SEALANT OUTFLOW
SEALANT FLOWING
OUT FROM UNDER
BAND CLAMP AT
BREECH
TWIST SPIN SLEEVE TIGHTLY INTO
BREECH COLLAR
445 01 4024 05
