ICS iC 525 User Manual

OPERATING AND MAINTENANCE MANUAL
Chapter 3 - Technical data
iC 215 ÷ iC 780
15
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
3.2 Data for standard units
3.2.1 Dimensions
See attached drawings.
3.2.2 Characteristics of pumps and fans
50Hz version:
Model iC 215 iC 220 iC 303 iC 305 iC 408 iC 410 iC 412 iC 416
Tank
capacity
water volume (litres) 60 60 115 115 140 255 255 255
Pump P3
water flow rate
(m
3
/h)
0.4/4.8 0.4/4.8 0.7/6 0.9/6 1.9/9.1 2.1/9.3 2.6/18 3.2/18
pump pressure
head
(bar) 3.0/1.4 3.0/1.4 3.1/1.6 3.0/1.5 3.0/1.5 2.9/1.6 2.8/1.7 2.8/1.7
rated power (kW) 0.55 0.55 0.75 0.75 0.9 0.9 1.85 1.85
Pump P5
water flow rate
(m
3
/h)
0.4/4.8 0.4/4.8 0.7/4.3 0.9/4.5 1.9/12.6 2.1/12.6 2.6/12.6 3.2/12.6
pump pressure
head
(bar) 5.4/3.0 5.4/3.0 5.3/3.7 5.2/3.5 5.2/3.2 5.2/3.6 5.2/3.6 5.1/3.7
rated power (kW) 1.1 1.1 1.1 1.1 2.2 2.2 2.2 2.2
Axial flow
fan
No. of fans 11111222
total airflow
(m
3
/h)
3500 3150 6500 6150 8150 14200 13600 13600
Centrifugal
fan
No. of fans ----112222
residual
pressure
(Pa) -- -- 159 188 265 134 115 115
total airflow
(m
3
/h)
-- -- 6600 6000 9200 12800 12800 12800
Model iC 520 iC 525 iC 530 iC 535 iC 538 iC 540 iC 640 iC 650
Tank
capacity
water volume (litres) 350 350 350 350 410 410 500 500
Pump P3
water flow rate
(m
3
/h)
3.4/18 3.4/18 4.8/27 5.6/27 7.2/35 8.0/35 6.6/48 8.1/48
pump pressure
head
(bar) 2.8/2.1 2.8/2.1 3.3/0.9 3.3/0.9 3.5/2.5 3.5/2.5 3.9/1.5 3.8/1.5
rated power (kW) 1.85 1.85 2.2 2.2 4 4 4 4
Pump P5
water flow rate
(m
3
/h)
3.4/27 3.4/27 4.8/27 5.6/27 7.2/42 8.0/42 6.6/48 8.1/48
pump pressure
head
(bar) 5.2/2.4 5.2/2.4 5.1/2.4 5.1/2.4 5.3/4.2 5.3/4.2 5.5/3.1 5.5/3.1
rated power (kW) 4 4 4 4 7.5 7.5 7.5 7.5
Axial flow
fan
No. of fans 22332222
total airflow
(m
3
/h)
16200 16000 22000 21600 37000 35000 45800 44400
High
pressure
axial flow
fan
No. of fans 22332222
residual
pressure
(Pa) 151 144 150 142 186 194 198 185
total airflow
(m
3
/h)
14600 14600 20100 20100 37000 35000 40000 40000
