OPERATING AND MAINTENANCE MANUAL
Chapter 5 - Installation
iC 215 ÷ iC 780
24
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
ENGLISH
EN
5.3 Freeze protection
Even if the minimum operating temperature is higher than 0°C, during shutdown periods in the cold season the unit may be
subject to temperatures that are lower than 0°C.
In such cases if the water is not drained out of the unit ethylene or propylene glycol antifreeze should be added to the water
in the following percentages:
In accordance with the chilled water outlet temperature, to avoid the formation of ice ethylene or propylene glycol antifreeze
should be added to the water in the following percentages:
The water flow rate must correspond to the value stated in the technical specifications or in the selection software.
The conditions specified in the table do not guarantee anti-freeze protection with the machine operating in bypass mode
between water delivery and return, and with the machine water inlet and outlet fittings shut off.
The anti-freeze setting is 4°C. To reduce the anti-freeze setting edit parameter AL26.
5.3.1 Operating limits
The operating limits are decided at the time of sale. Refer to the data specified in the contract.
For water outlet temperatures <= +5°C we recommend the use of anti-freeze solutions (compatible with the contact
materials);
(1) value referred to the unit chosen with the configurator option “-20°C ambient”. The unit is thus equipped with electronic
fans control and electrical cabinet heater.
If glycol is not used in the circuit it is advisable to equip the unit with anti-freeze heaters;
(2) reference value for the range with outlet water temperature of 15°C.
Ambient T up to
[°C]
Ethylene Glycol
[% by weight]
Propylene Glycol
[% by weight]
0 0 0
-5 15 18
-10 25 27
-15 30 33
-20 40 40
Water outlet T up to
[°C]
Ethylene Glycol
[% by weight]
Propylene Glycol
[% by weight]
Standard machine
7 0 0
3 20
20
0 20
25
-3 25
30
-5
30 30
-7 35
35
-10 35 40
Special machine
-15 45 45
-20 50 50
Ambient air temperature
Evaporator water
inlet temperature
Evaporator water
outlet temperature
Water temperature
gradient
Min Max Min Max Min Max Min Max
Fans control type
°C °C °C °C
-5
43
(2)
035-530
4 10 ON/OFF
5
43
(2)
-5 35 -10 30
-5
43
(2)
-5 35 -10 30
4 10 ELECTRONIC
-20
(1)
43
(2)
-5 35 -10 30
