ICT ICT200DF-12 User Manual

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 4 of 46
2.3 Package Contents
• Distribution panel
• Instruction manual (in bag)
• Four black plastic boots to insulate main DC power connections (in
bag)
• Two 3-pin alarm output connector plugs (in bag)
• One 10-pin site monitor alarm input connector plug (in bag)
• Six ICT-BLP breaker blanking plugs for installation in unused
breaker locations (in bag)
2.3.1 Tools and Parts Needed
• 1/2-inch wrench
• 3/8-inch wrench
• Wire stripper
• Four #10-32 Phillips screws (length to be decided by installer) to
connect rack ears to rack
• #2 Phillips screwdriver for the rack ear connections
• 3/32-inch flathead screwdriver for the form-C alarm relay
connector, alarm and sensor wire connection
2.3.2 Other Requirements
To complete the installation, appropriate circuit breakers (available from
ICT) are needed for each output channel that the user plans to use. Circuit
breakers must be ordered separately from the following list for use on the
ICT200DB-12IRC unit.
Table 1. Breakers
ICT Model
Rating (65 VDC)
ICT-CB5
5 A
ICT-CB10
10 A
ICT-CB15
15 A
ICT-CB25
25 A
ICT-CB30
30 A
ICT-BLP
Blanking Plate
NOTE: "C" series rocker handle circuit breakers with 0.25-inch tab terminals
and current ratings up to 30 amps may also be used. Consult ICT
for suitable part numbers.
2.4 Rack Mounting
Mount the unit in an enclosed standard 19-inch equipment rack or other
restricted access location, using rack mounting screws (not supplied).
Support the rear of the unit with rack shelf supports or back rail if required.

ICT ICT200DF-12 Specifications

General

Brand	ICT
Model	ICT200DF-12
Category	Power distribution unit
Language	English
