Table 5. Distribution Unit Alarms
Alarm
Trigger Condition
Channel
Output
Bus
Alarm
LED
1
Bus
Alarm
Contact
1
Send
E-mail
Breaker Off
Breaker opens or is
removed
Off
On
On
Yes
Bus
Undervoltage
Bus voltage drops
below undervoltage
threshold
No change
On
On
Yes
Bus
Overvoltage
Bus voltage rises above
the overvoltage
threshold
No change
On
On
Yes
Bus
Overcurrent
Bus current exceeds the
overcurrent threshold
(default 100 amps)
No change
On
On
Yes
Output
Overcurrent
Channel output current
exceeds overcurrent
threshold
Off
2
On
On
Yes
No power to
Unit
Loss of bus input power
source
Off
Off
On
-
Site Alarm
Input
Alarm on any external
input
No change
On
On
3
Yes
The unit may also be configured to send an alarm e-mail to multiple user e-
mail addresses for any of the alarm conditions (see Section 4.9) (no e-mail
will be sent if power is disconnected from the unit, due to loss of network
control).
4.0 OPERATION: GRAPHICAL USER INTERFACE
Connect to the Distribution Series 3 via Ethernet for full remote monitoring
and control using any standard web browser on a network connected
computer or phone. No additional software is required.
4.1 Log In/Log Out
1. Connect to the Distribution Series 3 by entering the IP address of
the unit in the location/address field of the browser as shown:
1
The Bus Alarm LED and Bus Alarm contact are enabled for Breaker alarms as the factory default setting;
all other alarms must be enabled in the appropriate setup page of the GUI by selecting the “Activate Alarm
Form-C Contact” check box for each alarm.
2
The channel may be user configured to disable the output for an Overcurrent Alarm.
3
Use the GUI to configure each alarm input to trigger either Bus A, B or both alarm contacts.
