V SERIES USER’S MANUAL
15
5.2.1 Press down the handle of paperweight wheel behind the machine to raise the
paperweight wheel.
5.2.2 Insert the media into the space between paperweight wheel and main shaft, and pull
out the media to appropriate length from the front of the host.
5.2.3 Move the paperweight wheel to the yellow identified
area, then adjust position of the media, a distance of
about 1-10CM is set between paperweight wheel and
media to ensure good running of media
The cutter adopts high-precision transmission shaft, and pay attention to the
position of the paperweight wheel. The paperweight wheel must be fixed above the yellow
identified area on the transmission shaft.
5.2.4 Raise two handles of paperweight wheel, to make paperweight wheel down to
press paper
