Manual IB-3640 Series
4
Avoid hitting the device with hard object, avoid shaking the player, and stay away from magnetic
fields.
During electrostatic discharge and the strong electromagnetic field, the product will
malfunction, and then unplug the power cable and the product will return to normal
performance next time it is powered on.
Note: All the information contained in this manual was correct at the time of publication.
However, as our engineers are always updating and improving the product, your device’s
software may have a slightly different appearance or modified functionality than presented in
this manual.
2. HARDWARE IB-3640 SERIES
2.1 FRONT VIEW LED INDICATION
IB-3640SU3
1. Blue Power on
Orange Sleep mode
2. USB in use / access
3. eSATA in use / access
4. Power button It needs to be pressed and held for 3 seconds to power off.
Remark! This design prevents accidental power off.
5. Interface button Function: Off
Function: LED blue – power off with PC
LED yellow – power off & power on with PC
7. Fan button Controls auto & manual modes and fan speed from level 1 to level 3.
8. eSATA link interface option
9. USB 3.0 link interface option
10. Smart Fan automatic mode
11. Smart Fan manual mode
12. Fan speed level 1 below 45 °C 1,200rpm ~ 1,800rpm
13. Fan speed level 2 45 °c · 54 °c 1,800rpm — 2,500rpm
4
5
6
7
3
16
2
1
17
18
19
10
11
12
13
14
15
8
9
