iDataLink ADS-ALCA - Wiring Information (continued); Type 2 Wire Chart

U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
LEXUS
GS350
PTS /
GS450h
PTS
13-15
CanH N20 Black 16 pin 06 Green (DATA) OBDII D
CanL N20 Black 16 pin 14 White (DATA) OBDII D
Ignition N24 Black 07 pin 06 Black (+) Steering lock B
SLP N24 Black 07 pin 04 Blue (-) Steering lock B
TX N12 White 30 pin 26 White (DATA) Main body ECU A
RX N12 White 30 pin 25 Black (DATA) Main body ECU A
Parking Light N12 White 30 pin 30 Black (-) Main body ECU A
PTS N43 Black 10 pin 01 Green (-) PTS button C
www.idatalink.comAutomotive Data Solutions Inc. © 2017 OEMALRSTL6ADSALCAEN
PAGE 8 OF 35
• 20170324
DOC.: #37575
