FAULT FINDING
FAULT FINDING FAULT FINDING FAULT FINDING FAULT FINDING FAULT FINDING
71 L.....E...... or H.....E...... (BOARD ERROR)
Internal fault within the PCB
Replace PCB
Press and hold reset button for 2
seconds. Does boiler operate
correctly?
Turn boiler off and wait for 5
seconds.Turn boiler on.
Does boiler operate correctly?
NO
NO
YES
OK
YES
OK
Check all earths for continuity.
Is continuity OK?
Correct Connection
HE ONLY: Check earth wire is
connected to detection lead.
Is this correct?
Correct wiring or replace
detection lead
LE ONLY:
Check Continuity of OH thermostat.
Is this correct?
Correct wiring or replace
thermostat
Check for an excess voltage
between neutral and earth.
Is the value below 50V?
Check earth connection to the boiler. If value is still
in excess of 50V consult a qualified electrician to
check the household electrical supply and circuitry
YES
YES
YES
YES
NO
NO
NO
NO
NO
