icos - Installation & Servicing
LIST OF PARTS
The following are parts commonly required due to damage or
expendability. Their failure or absence is likely to affect safety or
performance of this appliance.
The list is extracted from the British Gas List of Parts, which
contains all available spare parts.
The full list is held by British Gas Services, Ideal Stelrad Group
distributors and merchants.
When ordering spares please quote:
1. Boiler Model
2. Appliance G.C. Number
3. Description
4. Quantity
5. Product Number
Key No. GC Part No. Description Qty. Product No.
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Boilers Limited.
1 H42-807 Kit - Casing Front (Painted) 1 174 302
2 H42-808 Kit - Panel Case (Sealing) 1 174 303
4 H42-809 Kit - Panel - Side - RH/LH (Painted) 1 174 304
6 H42-810 Kit - Bottom Panel (Painted) 1 174 305
14 H29-002 Kit - Burner 1 174 080
17 E67-492 Kit - Injector & Housing 1 170 908
19 H07-771 Kit - Fan (FIME PX 130/0082) 1 173 525
22 H42-817 Kit - Gas Valve 1 174 306
25 H29-018 Kit - Thermistor - Dry Fire 1 174 087
26 H29-019 Kit - Thermistor - Boiler Control 1 174 088
27 H29-020 Kit - Thermostat - Overheat 1 174 089
28 H07-664 Kit - Electrode - Ignition 1 173 528
29 H07-665 Kit - Electrode - Flame Detection 1 173 529
34 H29-029 Kit - ‘S’ Trap 1 174 090
36 H29-031 Hose - ‘S’ Trap 1 174 091
37 H29-032 Kit - User Control 1 174 152
38 H29-034 Kit - PCB - Primary Control V9 1 174 486
39 E67-519 Kit - Fuse - 3.15A - PCB 1 170 931
41 H07-777 Mains Switch c/w Harness 1 173 537
42 H42-861 Kit - Spark Generator 1 174 307
45 H29-047 Kit - Gaskets - Servicing 1 174 096
46 H29-050 Gasket - Burner 1 174 093
54 H29-062 Kit - Earth Pin - Burner 1 174 086
68 H07-790 Lead - Ignition 1 173 510
69 H42-870 Kit - Lead - Detection 1 174 330
