- 22 -
IDEAL 3915-95
B
A
The 3 eccentrics are now exposed and should
be turned counter clockwise to position "0"
with the special wrench (A) (found in tool set).
Until the red arrow-like eccentric marking
corresponds to the position "0" (B).
Remove the special wrench and turn on the
main switch until the blade returns to the home
position.
Danger! Do not put main switch on position
"0" whilst blade is moving upwards! The clamp
must always overlap the blade! Risk of injury!
•
Blade and cutting stick replacement
•
Clamping
Blade
OK
OK
