- 23 -
3.
2.
1.
1.
3.
2.
4.
B
A
Position the main switch to "0" (1.)
Remove the 2 blade screws on the elongated
holes (2.). Then put the blade changing tool
into place and fasten it to the blade (3.).
The remaining screws should then be removed
(1.). Loosen the grips of the blade changing
tool (A) lightly (2.) will now allow the blade to
be taken downwards out of the machine (3.).
Place the blade into the blade carrier (B)
and screw it into place (4.).
•
Blade and cutting stick replacement
•
