Page 4
61-700
Function /
Range
Ranges Accuracy
200V, 50Hz - 500Hz 1.2% + 3digits
AC Voltage
200V, 50Hz - 1KHz 2.0% + 5 digits
600V, 50Hz - 500Hz 2.0% + 5 digits
DC Voltage 200mV/2000mV/200V/600V 0.5% + 1 digit
AC Current 200A, 50Hz - 60Hz 3.0% + 5 digit
200A, 60Hz - 400Hz 5.0% + 5 digit
Frequency 2K ~ 40KHz (Auto-ranging only) 0.1% + 3 digits
Resistance
200Ω/200KΩ
1.0% + 3digit
Diode Check
1mA ± 0.6mA
Not specified
Continuity
<100Ω on
Diode, Continuity
Not Specified
61-701
Function /
Range
Ranges Accuracy
200V, 50Hz - 500Hz 1.2% + 3 digits
AC Voltage
200V, 50Hz - 1KHz 2.0% + 5 digits
600V, 50Hz - 500Hz 2.0% + 5 digits
DC Voltage 2000mV/20V/ 600V 0.5% + 1 digit
AC Current 200A, 50Hz - 60Hz 3.0% + 5 digit
200A, 60Hz - 400Hz 5.0% + 5 digit
Capacitance 200MFD 3.0% + 5 digits
Frequency 2K ~ 40KHz (Auto-ranging only) 0.1% + 3 digits
Resistance
200Ω/200KΩ
1.0% + 3digit
Diode Check
1mA ± 0.6mA
Not specified
Continuity
<100Ω on
Diode, Continuity
Not specified
61-702, 61-704
Function /
Range
Ranges Accuracy
2000mV/200V, 50Hz - 500Hz 1.2% + 3digits
AC Voltage
2000mV/200V, 500Hz - 1KHz 2.0% + 5 digits
750V, 50Hz - 500Hz 2.0% + 5 digits
DC Voltage 2000mV/200V/1000V 0.5% + 1 digit
AC Current 200A, 50Hz - 60Hz 3.0% + 5 digit
200A, 60Hz - 400Hz 5.0% + 5 digit
Capacitance 200MFD 3.0% + 5 digits
Frequency 2K ~ 40KHz (Auto-ranging only) 0.1% + 3 digits
Resistance
200Ω/200KΩ
1.0% + 3digit
Diode Check
1mA ± 0.6mA
Not specified
Continuity
<300Ω on
Diode, Continuity
Not specified
AC Converter: Average responding, RMS Calibrated to Sine Wave
Overload Protection:
AC and DC Voltage: not to exceed 600V DC or VAC RMS for the model 61-700 and 61-701,
and 1000V DC or 750V AC for the 61-702 and 61-704
Resistance: Not to exceed 500V DC or AC RMS
Capacitance, Frequency, Diode Check, Continuity: not to exceed 500V DC or VAC RMS
Form number TM61700-1-2-4 Rev 4 September 2004
