These easy to install kits allow the boiler flue outlet to be extended external to the building,
upwards to provide a flue exit at high level, overcoming problems associated with plume
emission. The kit can be simply fitted retrofitted if necessary.
An external 60mm diameter flue leads from the boiler terminal (which includes a 90°
elbow at the flue exit) to terminate with a 90° elbow complete with grille. Push fit one
metre extension pipes are used as required, and the fixing clips supplied support the
system from the wall.
Both 90° and 45° elbows are available to provide routing options.
THE KIT COMPRISES:
Flue elbow - 1 off
60mm flue exit elbow - 1 off
60mm horizontal flue exit - 1 off
60mm x 500mm flue outlet extension pipe - 1 off
This kit is specified for use with the normal standard B pack.
The standard terminal nose is replaced with the high level terminal.
Diagram representative only.
ACCESSORIES
HIGH LEVEL FLUE OUTLET KIT.
69
