IDEAL SPLIT-JAW 61-096 User Manual

7 8
Specifications
1-1 General Specifications
Jaw opening:0.5”(12.7mm)Acceptsupto1/0copper
cable.
LCD display digits:6000digitlargescaleLCDreadout.
Measuring rate:5times/sec.
Overrange display:“OL”isdisplayedfor“Ω”function,
showstherealvaluefor“A”and“V”function.
Automatic power off time:Approximately30minutes
after power on.
Low battery indicator: is displayed. Replace the
battery when the indicator appears in the display.
Power requirement: 9Vbattery
Battery type and life: ALKALINEPP3,9V250hours
1-2 Environmental Conditions
Indoor Use.
Calibration: Oneyearcalibrationcycle.
Operating temperature:0°C~30°C(
<
80%RH)
  30°C~40°C(
<
75%RH)
  40°C~50°C(
<
45%RH)
Storage temperature: -20to+60°C,0to80%RH
(batteriesnotfitted)
Operating altitude:2000m(6562ft)
Overvoltage category:
IEC61010-1 CATIV600V
 CATIII1000V
IEC61010-1 CATIV600V
CATIVequipmentofOVERVOLTAGECATEGORYIVisforuseat
theoriginoftheinstallations.Noteexamplesincludeelectricity
metersandprimaryover-currentprotectionequipment.
Conductor Size:27mmdiameter
Pollution degree: 2
EMC:EN61326-1
Shock vibration:SinusoidalvibrationperMIL-T-
28800E(5~55Hz,3gmaximum)
Drop Protection:
4 foot drop to hardwood on concrete floor
1 - 3 Electrical Specifications
Accuracyis±(%reading+numberofdigits)at23°C±5°C
<80%RH.
Temperature coefficient:
0.2x(Specifiedaccuracy)/°C,<18°C,>28°C.
Voltage
Function Range Accuracy
V~ 1.3~750.0V
±(1.5%+3dgt)
50Hz~500Hz
V
1.8V~1000V ±(1%+2dgt)
-0.6V~-1000V ±(1%+4dgt)
Overload protection: 1000VDC/750VAC
Max Operation time: DT=30sfor
≥
30V
Input impedance:
≥
4Kforinputvoltageupto30V.
Impedanceincreaseswithinputvoltagetoapproximately
200KΩat600V.
...
Resistance & Continuity
Function Range Accuracy
Ω
•
))))
0.0Ω~99.9Ω ±(2%+1Ω)
100Ω~2000Ω
±(2%+2dgt)*
*Temperaturecoefficientmultipliesby1.5whenoperating
temperatureis40°C~50°C.
Overload protection: 1000VDC/750VAC
Max. open circuit voltage: 1.5V
Continuity check: Internalbeeperactivatesiftheresistance
ofthecircuitundertestislessthan25Ω.Itwillthenturnoff
iftheresistanceisincreasedbeyond400Ω.
AC Current
Function Range Accuracy
A~ 0.6A~200.0A
±(1.8%+3dgt)*
50Hz~60Hz
Overload protection: 400A ±(1.8%+6dgt)for
<
50A.
Max. open circuit voltage: 1.5V
Continuity check: Internalbeeperactivatesiftheresistance
ofthecircuitundertestislessthan25Ω.Itwillthenturnoff
iftheresistanceisincreasedbeyond400Ω.
Warranty Statement
Thistesteriswarrantedtotheoriginalpurchaseragainst
defects in material and workmanship for two years from
thedateofpurchase.Duringthiswarrantyperiod,IDEAL
INDUSTRIES,INC.will,atitsoption,replaceorrepairthe
defective unit, subject to verification of the defect or
malfunction.
Thiswarrantydoesnotcoverfuses,batteriesordamage
from abuse, neglect, accident, unauthorized repair, alteration,
or unreasonable use of the instrument.
AnyimpliedwarrantiesarisingoutofthesaleofanIDEAL
product, including but not limited to implied warranties of
merchantability and fitness for a particular purpose, are
limitedtotheabove.Themanufacturershallnotbeliable
for loss of use of the instrument or other incidental or
consequential damages, expenses, or economic loss, or for
any claim or claims for such damage, expenses or economic
loss.
Statelawsvary,sotheabovelimitationsorexclusionsmay
notapplytoyou.Thiswarrantygivesyouspecificlegal
rights, and you may also have other rights which vary from
state to state.
