Features
1. Taperedjawsw/hooktip
2. Lever
3. FunctionDial
4. MainDisplay(LCD)
5. Voltsandresistance(V-Ω)
input terminal
6. Common(COM)inputterminal
7. TightSight
®
bottom display
8. Protective rubber boot
9. MeasuringFunctions
10. HighVoltage(Hi-V)warning
11. Data&PeakHold
12. Max/min
13. Relative(61-763,61-773)
Relative/Zero(61-765,61-775)
14. Backlight
15. Capacitance()/Frequency(Hz)
16. Tactilebarrier
Common Features:
1
10
3
15
4
5
9
16
12
13
14
6
8
7
2
11
•Largenumbersandsymbolsdisplayed
•TightSight
®
bottom display
•Visualandselectableaudibleindication
when voltage is present
•MeasuresAC/DCVoltage,Resistance&
Capacitance
•Audiblecontinuity
•Bright,boldbacklight
•Peak,max/min,datahold
•SelectableAutopoweroffandlowbattery
indicator
•Taperedjawsforreachingintotightspaces
•Hooktipforeasierwireseparation
•Protectiverubberboot
•Electronicoverloadprotectiononall
ranges
•CatIV-600V/CatIII-1000V
•AllmodelsemployaHighFrequency
Reject(HFR)circuittofilternoiseor
help in making accurate measurements
oncomplexwaveshapeslikethose
foundonAdjustableSpeedDrives
(ASDs)
Model Specific Features:
•61-763:660AAC • 61-773:1000AAC
•61-765:660AAC/DC • 61-775:1000AAC/DC

Questions and Answers:
