6: ALLOCATION NUMBERS
6-8 « FC4A MICROSMART USER’S MANUAL »
Special Internal Relay Allocation Numbers (Read Only)
M8045 High-speed Counter 4 (I5-I7) Gate Input Maintained Cleared
M8046 High-speed Counter 4 (I5-I7) Reset Input Maintained Cleared
M8047 — Reserved — — —
M8050 Modem Mode (Originate): Initialization String Star t Maintained Maintained
M8051 Modem Mode (Originate): ATZ Start Maintained Maintained
M8052 Modem Mode (Originate): Dialing Star t Maintained Maintained
M8053 Modem Mode (Disconnect): Disconnect Line Star t Maintained Maintained
M8054 Modem Mode (General Command): AT Command Start Maintained Maintained
M8055 Modem Mode (Answer): Initialization String Star t Maintained Maintained
M8056 Modem Mode (Answer): ATZ Start Maintained Maintained
M8057 Modem Mode AT Command Execution Maintained Cleared
M8060 Modem Mode (Originate): Initialization String Completion Maintained Cleared
M8061 Modem Mode (Originate): ATZ Completion Maintained Cleared
M8062 Modem Mode (Originate): Dialing Completion Maintained Cleared
M8063 Modem Mode (Disconnect): Disconnect Line Completion Maintained Cleared
M8064 Modem Mode (General Command): AT Command Completion Maintained Cleared
M8065 Modem Mode (Answer): Initialization String Completion Maintained Cleared
M8066 Modem Mode (Answer): ATZ Completion Maintained Cleared
M8067 Modem Mode Operational State Maintained Cleared
M8070 Modem Mode (Originate): Initialization String Failure Maintained Cleared
M8071 Modem Mode (Originate): ATZ Failure Maintained Cleared
M8072 Modem Mode (Originate): Dialing Failure Maintained Cleared
M8073 Modem Mode (Disconnect): Disconnect Line Failure Maintained Cleared
M8074 Modem Mode (General Command): AT Command Failure Maintained Cleared
M8075 Modem Mode (Answer): Initialization String Failure Maintained Cleared
M8076 Modem Mode (Answer): ATZ Failure Maintained Cleared
M8077 Modem Mode Line Connection Status Maintained Cleared
Allocation
Number
Description CPU Stopped Power OFF
M8080
Data Link Slave Station 1 Communication Completion Relay (Master Station)
Data Link Communication Completion Relay (Slave Station)
Operating Cleared
M8081 Data Link Slave Station 2 Communication Completion Relay Operating Cleared
M8082 Data Link Slave Station 3 Communication Completion Relay Operating Cleared
M8083 Data Link Slave Station 4 Communication Completion Relay Operating Cleared
M8084 Data Link Slave Station 5 Communication Completion Relay Operating Cleared
M8085 Data Link Slave Station 6 Communication Completion Relay Operating Cleared
M8086 Data Link Slave Station 7 Communication Completion Relay Operating Cleared
M8087 Data Link Slave Station 8 Communication Completion Relay Operating Cleared
M8090 Data Link Slave Station 9 Communication Completion Relay Operating Cleared
M8091 Data Link Slave Station 10 Communication Completion Relay Operating Cleared
M8092 Data Link Slave Station 11 Communication Completion Relay Operating Cleared
M8093 Data Link Slave Station 12 Communication Completion Relay Operating Cleared
M8094 Data Link Slave Station 13 Communication Completion Relay Operating Cleared
M8095 Data Link Slave Station 14 Communication Completion Relay Operating Cleared
M8096 Data Link Slave Station 15 Communication Completion Relay Operating Cleared
M8097 Data Link Slave Station 16 Communication Completion Relay Operating Cleared
Allocation
Number
Description CPU Stopped Power OFF
