28: AS-INTERFACE MASTER COMMUNICATION
28-20 « FC4A MICROSMART USER’S MANUAL »
• Digital Output Data Image
Output Data Image (ODI)
Data Format
7
(DO3)
6
(DO2)
5
(DO1)
4
(DO0)
3
(DO3)
2
(DO2)
1
(DO1)
0
(DO0)
M1620 Byte 0 Slave 1(A) (Slave 0)
M1630 Byte 1 Slave 3(A) Slave 2(A)
M1640 Byte 2 Slave 5(A) Slave 4(A)
M1650 Byte 3 Slave 7(A) Slave 6(A)
M1660 Byte 4 Slave 9(A) Slave 8(A)
M1670 Byte 5 Slave 11(A) Slave 10(A)
M1680 Byte 6 Slave 13(A) Slave 12(A)
M1690 Byte 7 Slave 15(A) Slave 14(A)
M1700 Byte 8 Slave 17(A) Slave 16(A)
M1710 Byte 9 Slave 19(A) Slave 18(A)
M1720 Byte 10 Slave 21(A) Slave 20(A)
M1730 Byte 11 Slave 23(A) Slave 22(A)
M1740 Byte 12 Slave 25(A) Slave 24(A)
M1750 Byte 13 Slave 27(A) Slave 26(A)
M1760 Byte 14 Slave 29(A) Slave 28(A)
M1770 Byte 15 Slave 31(A) Slave 30(A)
M1780 Byte 16 Slave 1B —
M1790 Byte 17 Slave 3B Slave 2B
M1800 Byte 18 Slave 5B Slave 4B
M1810 Byte 19 Slave 7B Slave 6B
M1820 Byte 20 Slave 9B Slave 8B
M1830 Byte 21 Slave 11B Slave 10B
M1840 Byte 22 Slave 13B Slave 12B
M1850 Byte 23 Slave 15B Slave 14B
M1860 Byte 24 Slave 17B Slave 16B
M1870 Byte 25 Slave 19B Slave 18B
M1880 Byte 26 Slave 21B Slave 20B
M1890 Byte 27 Slave 23B Slave 22B
M1900 Byte 28 Slave 25B Slave 24B
M1910 Byte 29 Slave 27B Slave 26B
M1920 Byte 30 Slave 29B Slave 28B
M1930 Byte 31 Slave 31B Slave 30B
• Immediately after power up, the digital I/O data of standard slaves and expansion slaves cannot be
accessed. Data communication between the CPU module and the connected slaves starts when spe-
cial internal relay M1945 (Normal_Operation_Active) turns on. Make sure that M1945 is on before
starting to access the slave I/O data.
Caution
