2: MODULE SPECIFICATIONS
2-72 « FC4A MICROSMART USER’S MANUAL »
AS-Interface Module FC4A-AS62M
HMI Module FC4A-PH1
HMI Base Module FC4A-HPH1
10
17.7
37.5
23.5
90.0
4.5*
3.8
9.4 70.0
*8.5 mm when the clamp is pulled out.
35.0
42.0
38.0 13.9
71.0
90.04.5*
*8.5 mm when the clamp is pulled out.
All dimensions in mm.
