IDS NXT: Technical manual IDS NXT rome
5 IDS NXT rome
Dimensions height x width x length
Mechanical specifications
Mechanical specifications
IP 65
·
Protection against penetration of dust: No ingression of dust at
a vacuum of 20 mbar in the housing
·
Protection against water (out of a nozzle) from all directions
Test conditions: Using a jet nozzle with an inside diameter of
6.3 mm, a jet of water at a volume flow of 12.5 liters per minute
is applied to the housing from all directions at a distance of
2.5-3 m. The testing period is at least 3 min.
IP 67
·
Protection against penetration of dust: No ingression of dust at
a vacuum of 20 mbar in the housing
·
Protection against ingress of water in case of temporary
immersion
Test conditions: The housing is dipped completely under water
in a dip tank. The submerged depth is 1 m and the testing
period is 30 min. Water may not intrude in a quantity which
causes harmful effects while the housing is dipped in water
under standardized pressure and time conditions.
C-mount, see Optical specifications
Mounting holes bottom/top/side/front
Input I/O connector (M12): 12-24 V DC +20 %, max. 1 A
Input GigE connector (M12): PoE 41-57 V DC, max. 350 mA
12-pin M12 connector, screwable
Electrical specifications
Electrical specifications
5.1 Ambient conditions
The temperature values given below refer to the outer device temperature of the camera housing. The
temperature inside of the camera housing is generally higher than the outer temperature and may be up to
70 °C (158 °F).
Device temperature during operation
0 °C … 55 °C
32 °F … 131 °F
Device temperature during storage
-20 °C … 60 °C
-4 °F … 140 °F
20 % … 100 %, relative, non-condensing
* Only if IDS NXT rome lens tube and IP65/67 cables are used
