5. Specification
Model SR10 SR10U SR10B
Type A
ISK50 / IMC135: Up to 2 inches (5cm)
ISC80: Up to 4 inches (10cm)
Read Range
Type B N/A
ISC80B: Up to 2
inches (5cm)
N/A
Card Reading Time 30ms
Power / Current DC 12V / Max. 150mA
Input Port 2 Input Ports (External LED Control, External Buzzer Control)
34bit Wiegand (Default)
26bit Wiegand
(Default)
Output Format
RS232,ABA Track II (Selectable)
LED Indicator / Buzzer 3 Array LED Indicator(Red, Green) / Piezo Buzzer
Operating Temperature
-35° ~ +65℃ (-31° ~ +149℉)
Operating Humidity 10% ~ 90% Relative Humidity non-condensing
Color / Material Dark Peal Gray / Polycarbonate
Dimensions (W x H x T) 47mm X 115mm X 22 mm (1.8’’ X 4.5’’ X 0.88’’)
Weight 150g (0.33lbs)
Index of Protection IP65 / IP66
Certification FCC, CE, MIC
