IDTECK Star RF TINY - Features; Specification

4
3. Features
- 125KHz Proximity Card Reader
- PSK Modulation (IDTECK Format)
- Read Range: Up to 4 inches (10 cm)
- User Format Available
- 26bit Wiegand and RS232 (Default), ABA Track II (Optional) Output Format
- Dual Reading Technology Reader (Active and Passive Cards)
- Easy to Install on Metal Door Frame or Mullion
- External LED Control and External Buzzer Control
- Solid Epoxy Potted
- Waterproof (IP65/IP66)
- Reverse Polarity Protection
- Lifetime Warranty
- Options: Supervisory Signal
- Compatible Controllers: iCON100, iTDC, Standalone Controllers, Third-Party Controllers
4. Specification
Model RF TINY
CPU
8bit Microprocessor
IDK50 / IMC125: Up to 2 inches (5 cm)
IDC80: Up to 2.8 inches (7 cm)
Passive Type
IDC170: Up to 4 inches (10 cm)
Read
Range
Active Type
IDA150 / IDA200 Compatible
Reading Time (Card)
30ms
Power / Current
DC 12V / Max.180mA
Input Port
2 Ports (External LED Control, External Buzzer Control)
Output Format
26bit Wiegand (Default), RS232 and ABA Track II (Optional)
LED Indicator /
Beeper
2 Color LED (Red and Green) / Piezo Buzzer
Operating Temperature
-35° to +65°C ( -31° to +149°F )
Operating Humidity
10% to 90% relative humidity non-condensing
Color / Material
Dark Pearl Gray / Polycarbonate
Weight /
Dimension (W x H x T)
80g (0.18lbs)
/ 45mm x 85mm x 15.5mm
(1.77” x 3.35” x 0.6”)
Certification
FCC, CE, MIC
