Instruction Manual
STARTUP, OPERATION AND TEMPERATURE ADJUSTMENT
Operation
•Priortostockingcoolerwithproduct,itshould
be operated empty for half an hour.
Temperature Adjustment
REPAIR AND MAINTENANCE FOR REFRIGERATION DRAWER
* A CERTIFIED TECHNICIAN IS REQUIRED TO REPAIR ALL
REFRIGERATION COMPONENTS FOR WARRANTY PURPOSES.
For convenient repair, the refrigeration components (compressor,
evaporator,condenser,evaporationfan,condensationfanandlter)are
designed using a split system; any component can be easily replaced.
Replacementprocedureisasfollows:
1 Unplug the unit.
2 Removethescrewsfromthefrontgrill,andthenremovethegrill.
3 Unplug all connections and terminals that are in need of repair.
9
• G-10f/GCG-10f performance testing
position of the thermostat is around 4-6.
•Componentshownattheleft
functionsasasecondarypower
sourceforlowvoltageitemssuchas
signs.
4 Usingascrewdriver,removethe(3)screws
fromtherefrigerationdrawerbaseplate.
5 SlidetheRefrigerationDrawerouttoeasilyaccess
refrigeration components. Remove the component to replace or
repair.
6 Afterrepair,re-installallpartsusingthereverseprocedure.
Lit Door “Logo”
Switch
Operation
• For GCG-10f
coolers only.
Thelightswitch
located at the bottom
left hand side on the rear of the
cabinetistheON/OFFswitchforthe
Lit logo located on the door of cooler.
