COM
G3/(Y)
G2/(W)
G
LO
MED
HI
(HEAT)
(COOL)
(VALVE)
FAN
R
C
Sample Wiring Diagram
2-Pipe, Low Voltage Valve, Heat Only or Cool Only
COM
G
G3(Y)
G2(W)
R
C
G2
W1
G3
G
V
Y1
Thermostat
24 Volt Water
Valve
24vac
E025-71520303
E025-71520303
Page 8
