IEC E055-71520330 User Manual
4
of 1
of 1 rating
37 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
5
SCALE 1 : 1
Thermostat
If 2-pipe with
auxiliary electric heat
24vac
24 volt
water
valve
H
2
0 Changeover Sensor
(G100-71520306)
(closes below 60˚,
opens above 75˚)
R
G
Y1
G3
W1
G2
C
H2O
R
V
EH
C
R
C
G3
G2
G
COM
IEC relay board
L2
L2
LOW
MED
HIGH
L1
COM
COM
LOW
MED
COM
HIGH
2-Pipe, Low V
oltage V
alves,
H2O Changeover Sensor
Wiring Diagram
9
11
Table of Contents
Table of Contents
4
Front Panel
6
Thermostat Backplate
7
Wiring Diagrams
8
Connect to Wi-Fi
11
Display Legend
13
Basic Operation
15
User Setup
17
Clock
18
Enable Programmability
19
Backlight Operation
19
Installer Setup
20
Pipe Settings
20
Deadbands
21
Setpoint Limits & Lock Mode
22
Max Override Time
23
Display Units F/C
23
Remote Sensor
24
Pre-Occupancy Fan Purge
24
Water Valve Type
25
Dry Contact
26
Skyport Enable and API Enable
27
Locking/Unlocking the Keypad
28
Programming a Daily Schedule
29
About Advanced Features & Operation
31
Advanced Setup Table
35
