IFEX Technologies 3000 - Machinery and Tools for Maintenance

IFEX Technologies GmbH IFEX 3000 Impulse Fire Fighting Technology N°: IF3000-130
Instruction Manual
Instructions for Use and Operation
Page | 14
Hansestraße 18, 27419 Sittensen
Type IFEX 3072 Fire Extinguishing Unit with hose reel Date: 30.11.12
Page | 14
The fire extinguishing unit is now ready for use!
8.7 Place the IFEX 3001 Impulse Gun in the holder and secure it with the fixing strap.
8.8 Connect the air pressure hose (Delta connector) to the pressure regulator.
8.9 Connect the air pressure hose to the IFEX 3001 gun.
8.10 Connect the water hose to the IFEX 3001 gun (The water valve needs to be closed).
Machinery and tools for maintenance
The following list of tools is separate from the instructions.
The listed tools are to be used for their specific purposes only.
1. Test pressure gauge 0 bar to 400 bar
2. Double open-end wrench 13 x 15mm
3. Double open end wrench 14 x 17mm
4. Open-end wrench 21mm
5. Open-end wrench 26mm
6. Open-end wrench 27mm
7. Open-end wrench 32mm
8. Open-end wrench 36mm
9. Ring-wrench 8mm
10. Pipe angle wrench 13 x 110mm
11. Hook wrench 60-90 x 5mm
12. Hexagon screwdriver 3mm
(for inner hexagon screw)
13. Grease gun with lubricating grease
Torques:
¨ Front support grip 25 Nm
¨ Pistol grip (SW 3 inner hexagon) 7 Nm
¨ Fastening screws 30 Nm
¨ Ermeto- hose screw joints DN20 -18L 100 Nm
(Co-axial hose)
