IFEX Technologies 3000 - Hose Reel, Assembly (1)

Page | 17
IFEX Technologies GmbH
Hansestraße 18
D-27419 Sittensen
IFEX 3000
Index
Alteration
Date
Name
Impulse Fire
Extinguishing
Technology
Dimension without
tolerance acc.
DIN 7168-m
Surface
acc.
DIN ISO
1302
Name
Date
IFEX Code:
Scale
%
Breese
1
IFEX Code
19.04.
1999
Drawn
Check
Norm
Germany
IP-3100-1
4
Art.-n°
1
1
2
3
Ursprung : H:/CAD4/IFEX/HR-002-5
27060
=
127 127127
=
489
70
127 127127
546
508
4x boring Ø10,5
1
3
19
3
5
5
2
6
7
595
562
190
1
2
IF-3000-140E
G3/4"Water
- Lower (Rewind) position; Drum unbraked
- Middle (Braket) position; The brake is partially applied in order to control the drum during deployment of the hose. - Upper (Locked) position; The drum is fully applied. The position should be selected during transit or when the hose is in use is a positive lock on the drum is required.
Description and type
Drawing-n°
Qty
Item
Hosereel Assembly
H:/CAD-Tetra/Ifx3072-engl/IFX30100E
4
1
1
5
6 7
3
2
1 1 1
1
IF-HR-30001-4-1 IF-HR-30001-4-2
65056
IF-SL-300006-2-1
1/4" Air pressure swingjoint (Part at 1) 3/4" Water swing joint (Part at 1)
Rewind handle
G1/2" Water Connection
G1/8" Connection elbow with Plasticpipe
Hosereel compl. with 55 m hose. Mat. steel sheet red painted, 24V-E-electric rewind
CO-axial Hose 3/4"+1/4" Assy.
Greasenippel
G1/4" Air
3. Hose reel, assembly (1)
