Iflight COMMANDO 8 Lite User Manual

13
VIII. Wired Simulator
IX. Gimbal Mode and Calibration
1. Example: Mode1 to Mode2
-Loosen the centering screw on your left hand gimbal
until the stick centers itself.
-Adjust the left hand gimbal resistance screw to
your preference.
-Tighten the right hand centering screw to lock
self centering.
-Adjust the right hand gimbal resistance screw to
your preference.
2. The default MODE for the Commando 8 Lite is Mode2, users can switch the
mode according to their own habits, the throttle stick mode switching method
is as follows
-Disassemble the RF module cover, you can see a 2-digit DIP switch, set the switch to the
specified position according to the diagram below to switch the stick mode.
Gimbal mode
switch
Mode 1 Mode 2 Mode 3 Mode 4
Resistance screw
Tighten to increase the resistance,
loosen to reduce the resistance
Tighten for throttle use,Loosen for self centering
Centering switch screws
1
ON
KE
2
Power on the remote control, then connect the computer with a
USB-C cable and automatically enter simulator mode.
Power on
Connect with a USB-C cable
1
2
