ifm Operating Instructions IO-Link Master with Profinet interface PowerLine 8 Ports IP 65 / IP 67 (AL1202) 2017-06-02
Operating and display elements
>
7.1 Overview
22409
Status LEDs RDY, BF und SF
→ Status LEDs (→ p. 23)
Status LEDs LNK and ACT of the Profinet
interfaces 1 (X21) and 2 (X22)
→ Ethernet interface (→ p. 23)
Status LEDs US and UA of the voltage supply
(X31/X32)
→ Voltage supply (→ p. 24)
Status-LEDs IOL and DI of the IO-Link port Class A
(X01...X04)
→ IO-Link ports (Class A) (→ p. 24)
Status LED IOL of the IO-Link port Class B (X05...X08)
→ IO-Link ports (Class B) (→ p. 24)
