ifm Operating Instructions IO-Link Master with Profinet interface PowerLine 8 Ports IP 65 / IP 67 (AL1202) 2017-06-02
Appendix
>
12.1.1 Application
23710
Application
Application
I/O modules for field applications
Daisy-chain function
Voltage supply; communication interface
>
12.1.2 Electrical data
1862
Electrical data
Operating voltage [V]
20...30 DC; (US; to SELV/PELV)
Current consumption [mA]
300...3900; (US)
Protection class
III
Additional voltage supply [V]
20...30 DC; (UA)
Sensor supply US
Max. current load total [A]
3.6
Actuator supply UA
Max. current load total [A]
3.6
>
12.1.3 Inputs / outputs
23711
Inputs / outputs
Total number of inputs and outputs
12; (configurable)
>
12.1.4 Inputs
22820
Inputs
Number of digital inputs
12; (IO-Link Port Class A: 4 x 2; IO-Link Port Class B: 4 x 1)
Switching level high [V]
11...30 DC
Switching level low [V]
0...5 DC
Digital inputs protected against short circuits
yes
