IFM Electronic AL1202 - Reboot the device; Error detection and elimination

56
ifm Operating Instructions IO-Link Master with Profinet interface PowerLine 8 Ports IP 65 / IP 67 (AL1202) 2017-06-02
Operation
>
9.3 Reboot the device
12760
When restarting the device, all settings are kept.
To restart the AL1202:
► Start LR DEVICE.
► Scan the network for devices.
> LR DEVICE recognises the AL1202.
► Under [ONLINE]: Click on [AL1202]
► Select the [Setup] section.
> LR DEVICE shows available parameters.
► Click on [Restart] to restart the device.
> LR DEVICE restarts the AL1202.
>
9.4 Error detection and elimination
11610
In order to recognise and eliminate errors, the user can use the following resource:
 Status LED of the unit (→ LED indicators (→ p. 23))
 Acyclic alarms and diagnostic messages (→ Diagnostic and alarms (→ p. 75))
