32
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen We reserve the right to make technical alterations without prior notice! 24.10.2014CR0411 / page 6
CR0411 Technical data
Control systems
Wiring
A B C D E F N2 P/N1
8 poles 4 poles 6 poles
VBB
S
IN0
IN1
GND
GND
IN2
IN3
VBB
S
VBB
S
IN4
IN5
GND
GND
IN6
IN7
VBB
S
OUT0
GND
OUT1
GND
OUT2
GND
OUT3
GND
OUT4
GND
OUT5
GND
OUT6
GND
OUT7
GND
VBB
S
GND
CAN2_H
CAN2_L
VBB
S
VBB
1
VBB
2
GND
CAN1_H
CAN1_L
C/F = not used
Abbreviations A
B
H
B
L
FRQ
H
PWM
PWM-I
R
VBB
S
VBB
1
VBB
2
Analogue
Binary high side
Binary low side
Frequency/pulse inputs
H-bridge function
Pulse width modulation
Pulse width modulation, current-controlled
Resistor input
Supply sensors/module
Supply OUT 0...3
Supply OUT 4...7
